Description

Caracteristici:

- Sintetizator polifonic two-part multitimbral 16-voice

- 3 oscilatoare NCO New Oxford per voce, ce ofera sinteza subtractive, wavetable sau FM

- Filtru multimod analog 12/24dB per voce cu Dual mode

- Claviatura premium semigrea de 5 octave, cu sensibilitate la velocitate si aftertouch

- Efecte per-part: distortion, chorus, delay si reverb

- Iesiri efecte si aux stereo rutabile intern

Specificatii tehnice:

Engine sintetizator

- polifonie 16 note

- 2-part-timbral

- Moduri Layered, Split, Dual Bi-Timbral

- Moduri 5 Voi - Mono, MonoLG, Mono2, Poly, Poly2

Per voce

- 3 oscillatoare

- 1 noise generator cu HP filter control

- 1 ring modulator

- 2 LFO-uri

- 1 amp envelope si 2 mod envelopes (ADHSR + looping)

- 1 filtru

Waveform-urile includ:

- Sine, tri, sawtooth, square / pulse, plus 43 wavetable-uri de 5 waveform-uri pe rand

Filtru:

- 1 filtru OTA state variable per voce

- 12/24dB slope

- Low-pass / band-pass / high-pass / dual filter

- Filtru dual: LP >. HP, LP >. BP, HP >. BP, LP + HP, LP + BP, HP + BP, LP + LP, BP + BP, and HP + HP

- overdrive pre-filtru

- Distortion pre-filtru

Modulatie:

- 16 slot-uri de modulatieper patch

- 2 sources per destination per slot

Surse modulatie:

- Direct (depth)

- Modulation wheel

- Aftertouch (polyphonic and channel AT)

- Expression pedal 1

- Expression pedal 2

- Keyboard velocity

- LFO1 positive

- LFO1 bi-polar

- LFO2 positive

- LFO2 bi-polar

- Amp envelope

- Mod envelope 1

- Mod envelope 2

- Animate 1

- Animate 2

- CV mod input bi-polar

- Bend Up

- Bend Down

Destinatii modulatie:

- Oscillator 1-3 frequency, v-sync level, shape amount and level

- Noise source level

- Ring modulator output level

- Overall synth output level

- Filter drive, distortion, cut-off frequency and resonance

- LFO 1 and 2 frequency

- Amp env / mod env 1 / mod env 2 attack, decay and release

- FM Osc 1 ->. osc 2, osc 2 ->. osc 3, osc 3 ->. osc 1 and noise ->. osc 1

- Osc 3 ->. filter cutoff frequency

- Noise ->. filter cutoff frequency

Efecte:

- FX are per part

- Analogue distortion

- 3 chorus types

- Delay with 16 types of delay sync, LP and HP damping, slew and stereo

- 3 reverb types

Sursa Matrice FX Mod:

- Direct (depth)

- Mod wheel

- Aftertouch

- Expression pedal 1

- Expression/breath pedal 2

- Velocity

- Keyboard

- LFO 1 +/-

- LFO 2 +/-

- LFO 3 +/-

- LFO 4 +/-

- Amp envelope

- Mod envelope 1 & 2

- Animate 1 & 2

- CV +/-

- Bendwheel +/-

- Bend up

- Bend down

Destinatii Matrice FX Mod:

- Distortion level

- Chorus level

- Chorus rate

- Chorus depth

- Chorus feedback

- Delay level

- Delay time

- Delay feedback

- Reverb level

- Reverb time

- Reverb low pass

- Reverb high pass

Diverse:

- FM controls on front panel

- Global LFO 3 & 4

- Arpeggiator with key latch-  33 patterns

- Patch storage - up to 512 on hardware (ships with 256 factory patches)

- Glide control

- All knobs (excl. volume), sliders and most buttons transmit and receive MIDI cc commands for external control and mapping

- Microtuning with Scala table import and table tuning creation

- Manual mode

- Multi pot mode: Relative, Pot pick-up, Snap

Specificatii hardware produs:

- 50 control knobs

- 8* 45mm sliders

- 1 volume knob

- 1 data encoder knob

- Rubberised knob caps with spun metal discs

- 55 function buttons

- 2 Animate buttons plus hold button

- OLED display

- Kensington Lock

- Power switch

- IEC power supply connector

- USB socket for system (MIDI comms only, no bus power)

- MIDI In / Out / Thru

- 2x 1/4inch jack sockets for continuous or switched pedals

- 1x 3.5mm jack socket for CV in

- 2x 1/4inch jack sockets for left and right outputs

- 2x 1/4inch jack sockets for left and right auxiliary outputs

- 2x 1/4inch jack sockets for left and right inputs

- 2x 1/4inch jack socket for headphone output

- Metal chassis with American walnut wooden end cheeks

- Metal magnetic inset end pieces

Compatibilitate software:

- Ableton Live Lite is included

- Summit is a USB-MIDI class compliant device

Dimensiuni:- 998.4 x 302.4 x 71 mm

Greutate:- 11 kg

Pachetul contine

:- Sintetizator Novation Summit

- Cablu USB

- Ghid utilizator

- Alimentator
